Equipment directory

Pictures, connections, and related guidance for the equipment at your wash.

UniFi Express 7 — UniFi Express 7 product image from Ubiquiti; packaging is pictured.UniFi Express 7 The site gateway between the internet connection and the NXT Wash core switch.NXT Wash 24-port primary switch 24-port primary switch connecting the site’s network equipment.Pay-station PoE switch The switch inside a pay station connects its local devices and the cable back to the building.Pay-station middleware — Middleware computer product views by the operator.Pay-station middleware Runs the lane software and connects the screen, scanner and cash devices to NXT Wash.POS middleware — Middleware computer product views by the operator.POS middleware The equipment-room computer that links NXT Wash POS software with site equipment.LPR server Jetson — Jetson product views by the operator.LPR server Jetson Processes the lane camera feed for license-plate recognition.PAX IM30 — PAX IM30 front view. From NXT Wash Site Network Topology; image by the operator.PAX IM30 The card reader mounted in the customer-facing pay-station panel.RFID reader Reads a member’s windshield tag at the lane.LPR camera — Axis camera product photo by the operator.LPR camera Captures the lane image used for plate recognition.Legacy POS System XPT5 — XPT5 interior photo from the retrofit guide.Legacy POS System XPT5 Legacy POS System pay station converted to NXT Wash with a replacement screen, middleware PC and IM30; HDMI carries picture and USB carries touch.ICS Auto Sentry — ICS pay-station photo from the retrofit guide.ICS Auto Sentry Pay station converted to NXT Wash using a new faceplate, IM30 and Beetronics display.Bill acceptor — Bill-acceptor photo from the Legacy POS System export.Bill acceptor Accepts banknotes at the pay station.Bill dispenser — Bill-dispenser photo from the Legacy POS System export.Bill dispenser Dispenses banknotes from the pay-station vault.XPT display module — Original XPT display assembly · Legacy POS System reference photo.XPT display module Original XPT display assembly for legacy identification. White Water installs a replacement screen with direct HDMI and USB connections to middleware.Lane gate — Lane gate with the barrier arm raised. Photo by the operator.Lane gate Controls vehicle entry from a pay lane.POS terminal — POS station with touchscreen, keyboard and cash drawer. From NXT Wash Site Network Topology; image by the operator.POS terminal The cashier terminal used to sell washes and manage customer transactions.PAX A35 The card reader used at the cashier POS station.PAX A77 — PAX A77 handheld payment reader. From NXT Wash Site Network Topology; image by the operator.PAX A77 A handheld card terminal used by staff in the lanes and connected over Wi-Fi. NXT Wash Wi-Fi network names end in -N.Tunnel loader — Tunnel loader screen in its protective enclosure. From NXT Wash Site Network Topology; image by the operator.Tunnel loader The attendant’s screen for the vehicle queue and sending vehicles into the wash.TunnelWatch TCS1 — TunnelWatch TCS1 controller cabinet — photo and identified by the operator.TunnelWatch TCS1 TunnelWatch TCS1 controller for tunnel equipment and wash functions. White Water uses TCP/IP on VLAN 120 through primary-switch port 22.TunnelWatch TCS2 — TCS2 boards and connection labels · from the vault’s TunnelWatch TCS2 guide.TunnelWatch TCS2 TunnelWatch controller covered by the White Water cutover and tunnel-network guides. White Water uses TCP/IP on VLAN 120 through primary-switch port 22.Kesseltronics rTC — Equipment illustration; a product photo has not been added.Kesseltronics rTC Controls wash functions through the Kesseltronics rTC system.Wireless access point — Ubiquiti UniFi U7 Lite — recommended indoor AP. Manufacturer product image by the operator.Wireless access point Wireless access for site tablets and handheld readers. Recommended: U7 Lite indoors; U7 Outdoor outdoors. NXT Wash Wi-Fi names end in -N.Samsung Galaxy Tab Active5 — Galaxy Tab Active5 with S Pen · Samsung product image from the export.Samsung Galaxy Tab Active5 White Water’s site tablet for NXT Wash POS, kiosk or loader use. Connect to the assigned NXT Wash Wi-Fi network ending in -N.Volcora POS receipt printer — Volcora POS receipt printer — product photo by the operator.Volcora POS receipt printer Volcora printer for POS receipts, connected by USB to the terminal with the cash drawer connected to the printer.Barcode scanner — Equipment illustration; a product photo has not been added.Barcode scanner Reads barcodes at the pay station or POS. The conversion guides connect the replacement scanner by USB.Beetronics touchscreen — Equipment illustration; a product photo has not been added.Beetronics touchscreen Replacement touchscreen used in the ICS conversion, with HDMI video and USB touch connected to middleware.Eaton SMART1500LCD battery backup — front view of the Eaton Tripp Lite SMART1500LCD.Eaton SMART1500LCD battery backup The selected 2U battery backup at the bottom of the White Water rack.
